ProDemo™ PDR170D Professional Demolition Robots
- Range, radio : 100m
- Power : 22kw
- System pressure : 19MPa
- Hydraulic system capacity : 80L
- Transport speed, max. : 3.0km/h
- Climbing inclination, max. : 30°
ProDemo™ PDR170D is small and compact, small in size, light in weight and has excellent crushing capacity and powerful force. ProDemo™ PDR170 is our most powerful remote-controlled demolition robot with a telescopic arm, extending the reach for a flexible set-up.
Despite its low weight and compactness it delivers a power of 22 kW, making it ideal for efficient demolition in tough environments. The outriggers are individually controlled and combined with a large footprint provides superior stability which enables high workload.
PDR170D Techical Data of Demolition Robot
| Slewing speed | 12sec/360° |
| Transport speed, max. | 3.0km/h |
| Climbing inclination, max. | 30° |
| Hydraulic system capacity | 80L |
| Pump type | Variable load-sensing |
| System pressure | 19MPa |
| Pump flow | 0-60L/min |
| Electric motor type | YE3-180L-4B35 |
| Power | 22kw |
| Recommended fuse size | / |
| Starting device | Direct start |
| Control type | SmartRemote |
| Signal code | Digital |
| Transfer | Professional radio/Cable |
| Range, radio | 100m |
| Machine weight | 1850kg |
| Recommended attachment weight | 270kg |
PDR170 is a versatile machine for both the construction and process industry. Combine it with a variety of tools like hammers or our compact and versatile crushers and steel shearer. For the toughest applications we recommend our additional feature packages .
It is widely used in construction demolition and metallurgical slag breaking industries. It can enter narrow porches and door openings of metallurgical furnaces and kilns, and complete demolition operations efficiently. Its main features are small machine, powerful force and precise demolition.
