ProWire Diamond Wire for Multi Wire Machine for Granite Block Cutting into Slabs
- Brand Name: ProWire
- Type Power: Tool Parts
- Quality of Steel Cable: 100% German Made
- Diameter of Beads: 6.2mm, 6.4mm, 7.3mm, 7.5mm
- Beads/Meter: 36, 37
- Fix Method: Plastic Coating
- Diamond: Element Six
- Machine: Diamond Wire Saw Machine
- Loop: Endless Loop
Prodrill new product ProWire for stone cutting: Diamond Multi Wire is a newest diamond wire materials used by granite multi wire saw machine to saw granite slabs to replace traditional granite gang saw.
Diamond Multi Wire is suitable for all kinds of granite slab cutting with following specialties:
High cutting efficiency, 10-15 times than granite gang saw machine,
Smooth cutting surface, get the even and smooth slab,
Always involve low power consume and less raw material waste,
Low noise and friendly surroundings,
Easy manipulation and with high yield, low cost, safety and environmental protection etc.
Technical Features:
Suitable for multi wire saw with 5 to 60 wires as a group.
Injecting endless diamond wire is applied to lower wire broken off.
Strong cable with very little distortion effectively reduces mutual interference between the closed loop wire when cutting.
Wire pre-sharpened by machine to ensure easy starting on all kind of granite.
Used to the end of its life without the need for re-coating on it.
Perfect to match with SIMEC, Universo, Gaspari, Pellegrini and Bidese(Breton) multi wire saw machines.
Wire Specification:
Item NO.
Bead Diameter (mm)
Beads/Meter
Application
Coating
PW18
φ7.2
37
Granite Slabs
High Strength Plastic
PW20
φ6.2
37
High Strength Plastic
Parameters:
Application
Wire Speed(m/s)
Cutting Speed(m2/h)
Life(m2/h)
Soft Granite
28-32
0.7-1.3 (Pcs No.)
6-13
Medium Hard Granite
28-32
0.5-1.0 (Pcs No.)
4-8
Hard Granite
25-30
(Pcs No.)
2-6
Bead Specification:
Bead Diameter(mm)
Working Layer Height(mm)
Support length(mm)
Bead Type
φ7.2
H6.5，H7.0
10.5
Sintered
φ6.2
H6.5，H7.0
10
Sintered
Other specifications are available according to customer\'s requirements.
Productivity of Prodrill ProWire Diamond Multi Wire: Modern gang saw can produce 3000 to 4000 square meters of 2 cm thickness slabs, ProWire Diamond Multi Wire can produce 5000 to 6000 square meters of slabs cut at any thickness between 1 to 5 cm.
ProWire Diamond Multi Wire most common specs:
1. φ7.3mm Beads, 24.5 LM Diamond Wire, 36 Beads per LM for Granite Multi Wire Saw Machine;
2. φ7.5mm Beads, 17.5 LM Diamond Wire, 37 Beads per LM for SIMEC Granite Multi Wire Saw Machine.
